2-3 Cascaded_Dense_Layers 구현

Shapes of cacaded Dense Layers¶

In [1]:

import tensorflow as tf

from tensorflow.keras.layers import Dense

N, n_feature = 4, 10
X = tf.random.normal(shape=(N, n_feature))

n_neurons = [3, 5]
dense1 = Dense(units=n_neurons[0], activation="sigmoid")
dense2 = Dense(units=n_neurons[1], activation="sigmoid")

# forward propagation
A1 = dense1(X)
Y = dense2(A1)

# get weight/bias
W1, B1 = dense1.get_weights()
W2, B2 = dense2.get_weights()

print("X: {}\n".format(X.shape))

print("W1: ", W1.shape)
print("B1: ", B1.shape)
print("A1: {}\n".format(A1.shape))

print("W2: ", W2.shape)
print("B2: ", B2.shape)
print("Y: {}".format(Y.shape))

X: (4, 10)

W1:  (10, 3)
B1:  (3,)
A1: (4, 3)

W2:  (3, 5)
B2:  (5,)
Y: (4, 5)

Dense Layers with Python List¶

In [1]:

import tensorflow as tf

from tensorflow.keras.layers import Dense

N, n_feature = 4, 10

X = tf.random.normal(shape=(N, n_feature))

n_neurons = [10, 20, 30, 40, 50, 60, 70, 80, 90, 100]

dense_layers = list()

for n_neuron in n_neurons:
    dense = Dense(units=n_neuron, activation="relu")
    dense_layers.append(dense)
print("Input: ”", X.shape)

for dense_idx, dense in enumerate(dense_layers):
    X = dense(X)
    print("After dense layer", dense_idx + 1)
    print(X.shape, "\n")
Y=X

Input: ” (4, 10)
After dense layer 1
(4, 10)

After dense layer 2
(4, 20)

After dense layer 3
(4, 30)

After dense layer 4
(4, 40)

After dense layer 5
(4, 50)

After dense layer 6
(4, 60)

After dense layer 7
(4, 70)

After dense layer 8
(4, 80)

After dense layer 9
(4, 90)

After dense layer 10
(4, 100)

Output Calculations¶

In [ ]:

import tensorflow as tf

from tensorflow.math import exp
from tensorflow.linalg import matmul

from tensorflow.keras.layers import Dense

N, n_feature = 4, 5
X = tf.random.normal(shape=(N, n_feature))
X_cp = tf.identity(X)

n_neurons = [3, 4, 5]

dense_layers = list()
for n_neuron in n_neurons:
    dense = Dense(units=n_neuron, activation='sigmoid')
    dense_layers.append(dense)
print(X_cp.shape)

# forward propagation(Tensorflow)
W, B = list(), list()
for dense_idx, dense in enumerate(dense_layers):
    x = dense(X)
    w, b = dense.get_weights()
    W.append(w)
    B.append(b)
    print("Y(Tensorflow): \n", X.numpy())


# forward propagation(Manual)
for layer_idx in range(len(n_neurons)):
    w, b = W[layer_idx], B[layer_idx]

    X_cp_ = matmul(X_cp, w) + b
    X_cp_ = 1/(1 + exp(-X_cp_))
    print("Y(Manual): \n", X_cp.numpy())

(4, 5)
Y(Tensorflow):
 [[ 0.06675826  0.48867878  0.3436861   1.2327288  -0.92616004]
 [-0.78806245  0.05966637 -0.37663674  0.50513923 -1.5538013 ]
 [-2.0325694  -0.32740903  0.26999393  0.15857382  1.9611359 ]
 [-1.2176428  -1.0491334   1.6158277  -0.09503141  1.9127471 ]]
Y(Tensorflow):
 [[ 0.06675826  0.48867878  0.3436861   1.2327288  -0.92616004]
 [-0.78806245  0.05966637 -0.37663674  0.50513923 -1.5538013 ]
 [-2.0325694  -0.32740903  0.26999393  0.15857382  1.9611359 ]
 [-1.2176428  -1.0491334   1.6158277  -0.09503141  1.9127471 ]]
Y(Tensorflow):
 [[ 0.06675826  0.48867878  0.3436861   1.2327288  -0.92616004]
 [-0.78806245  0.05966637 -0.37663674  0.50513923 -1.5538013 ]
 [-2.0325694  -0.32740903  0.26999393  0.15857382  1.9611359 ]
 [-1.2176428  -1.0491334   1.6158277  -0.09503141  1.9127471 ]]
Y(Manual):
 [[ 0.06675826  0.48867878  0.3436861   1.2327288  -0.92616004]
 [-0.78806245  0.05966637 -0.37663674  0.50513923 -1.5538013 ]
 [-2.0325694  -0.32740903  0.26999393  0.15857382  1.9611359 ]
 [-1.2176428  -1.0491334   1.6158277  -0.09503141  1.9127471 ]]
Y(Manual):
 [[ 0.06675826  0.48867878  0.3436861   1.2327288  -0.92616004]
 [-0.78806245  0.05966637 -0.37663674  0.50513923 -1.5538013 ]
 [-2.0325694  -0.32740903  0.26999393  0.15857382  1.9611359 ]
 [-1.2176428  -1.0491334   1.6158277  -0.09503141  1.9127471 ]]
Y(Manual):
 [[ 0.06675826  0.48867878  0.3436861   1.2327288  -0.92616004]
 [-0.78806245  0.05966637 -0.37663674  0.50513923 -1.5538013 ]
 [-2.0325694  -0.32740903  0.26999393  0.15857382  1.9611359 ]
 [-1.2176428  -1.0491334   1.6158277  -0.09503141  1.9127471 ]]

In [ ]:
