샘플 데이터와 Out-of-Distribution 모델¶

In [1]:

!pip install -U imbalanced-learn

Requirement already satisfied: imbalanced-learn in /usr/local/lib/python3.7/dist-packages (0.8.0)
Requirement already satisfied: numpy>=1.13.3 in /usr/local/lib/python3.7/dist-packages (from imbalanced-learn) (1.19.5)
Requirement already satisfied: scikit-learn>=0.24 in /usr/local/lib/python3.7/dist-packages (from imbalanced-learn) (0.24.2)
Requirement already satisfied: joblib>=0.11 in /usr/local/lib/python3.7/dist-packages (from imbalanced-learn) (1.0.1)
Requirement already satisfied: scipy>=0.19.1 in /usr/local/lib/python3.7/dist-packages (from imbalanced-learn) (1.4.1)
Requirement already satisfied: threadpoolctl>=2.0.0 in /usr/local/lib/python3.7/dist-packages (from scikit-learn>=0.24->imbalanced-learn) (2.2.0)

In [2]:

import pandas as pd
import numpy as np
import matplotlib.pyplot as plt


np.random.seed(2021)

1. Data¶

1.1 Sample Data¶

In [3]:

from sklearn.datasets import make_moons

data, label = make_moons(n_samples=300, shuffle=True, noise=0.5, random_state=2021)

In [4]:

plt.scatter(data[:, 0], data[:, 1], c=label)

Out[4]:

<matplotlib.collections.PathCollection at 0x7f16f8c49bd0>

1.2 Resample Data¶

In [5]:

from imblearn.datasets import make_imbalance
from collections import Counter


def ratio_func(y, multiplier, minority_class):
    target_stats = Counter(y)
    return {minority_class: int(multiplier * target_stats[minority_class])}

data, label = make_imbalance(
    data,
    label,
    sampling_strategy=ratio_func,
    **{"multiplier": 0.1, "minority_class": 1,}
)

In [6]:

plt.scatter(data[:, 0], data[:, 1], c=label)

Out[6]:

<matplotlib.collections.PathCollection at 0x7f16f3196810>

1.3 Split Data¶

In [7]:

normal_data, abnormal_data = data[label==0], data[label==1]
normal_label, abnormal_label = label[label==0], label[label==1]

In [8]:

normal_label

Out[8]:

array([0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
       0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
       0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
       0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
       0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
       0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
       0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0])

In [9]:

abnormal_label

Out[9]:

array([1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1])

In [10]:

from sklearn.model_selection import train_test_split

train_data, test_normal_data, train_label, test_normal_label = train_test_split(
    normal_data, normal_label, train_size=0.7, random_state=2021
)

In [11]:

test_data = np.concatenate([test_normal_data, abnormal_data])
test_label = np.concatenate([test_normal_label, abnormal_label])

In [12]:

plt.scatter(train_data[:, 0], train_data[:, 1], c=train_label)

Out[12]:

<matplotlib.collections.PathCollection at 0x7f16f3147c90>

In [13]:

test_label.mean()

Out[13]:

0.25

In [14]:

plt.scatter(test_data[:, 0], test_data[:, 1], c=test_label)

Out[14]:

<matplotlib.collections.PathCollection at 0x7f16f30bb290>

1.4 시각화 데이터¶

In [15]:

x_min, x_max = data[:, 0].min() - 1, data[:, 0].max() + 1
y_min, y_max = data[:, 1].min() - 1, data[:, 1].max() + 1
xx, yy = np.meshgrid(np.arange(x_min, x_max, 0.02),
                     np.arange(y_min, y_max, 0.02))

2. Isolation Forest¶

In [16]:

from sklearn.ensemble import IsolationForest

isol_forest = IsolationForest()

2.1 학습 & 예측¶

In [17]:

isol_forest.fit(train_data, train_label)

Out[17]:

IsolationForest()

In [18]:

isol_test_pred = isol_forest.predict(test_data)

In [19]:

isol_test_pred

Out[19]:

array([ 1,  1, -1,  1,  1,  1,  1,  1,  1,  1,  1,  1,  1, -1,  1, -1,  1,
       -1,  1,  1,  1,  1,  1, -1,  1,  1, -1,  1,  1,  1,  1,  1,  1,  1,
       -1,  1, -1, -1,  1,  1,  1,  1,  1,  1,  1, -1,  1, -1, -1,  1, -1,
       -1, -1,  1, -1, -1,  1, -1, -1, -1])

In [21]:

isol_forest.decision_function(test_data)

Out[21]:

array([ 0.07920637,  0.01568211, -0.0007057 ,  0.02886496,  0.02354266,
        0.0608095 ,  0.07836153,  0.07959195,  0.0777155 ,  0.08368566,
        0.08096668,  0.01768742,  0.08804025, -0.00679535,  0.09107424,
       -0.07279372,  0.09572535, -0.0502307 ,  0.03196264,  0.0340732 ,
        0.03109257,  0.05498848,  0.01211572, -0.18090731,  0.01593877,
        0.00788293, -0.06141088,  0.05915229,  0.04951808,  0.0617401 ,
        0.08176808,  0.00573826,  0.05432684,  0.07215502, -0.00099358,
        0.06042053, -0.00692154, -0.03889864,  0.04679394,  0.05090291,
        0.07737391,  0.0739545 ,  0.05009019,  0.07951504,  0.00591456,
       -0.11496344,  0.06394809, -0.09365931, -0.06585884,  0.02217839,
       -0.11233681, -0.06277224, -0.17346579,  0.0744311 , -0.14945106,
       -0.13751562,  0.08314092, -0.11029918, -0.09093424, -0.11188274])

2.2 평가¶

정확도

In [22]:

from sklearn.metrics import accuracy_score

isol_test_acc = accuracy_score(test_label, isol_test_pred == -1)

In [23]:

print(f"Isolation Forest Test Accuracy is {isol_test_acc:.4f}")

Isolation Forest Test Accuracy is 0.7833

F1 Score

In [24]:

from sklearn.metrics import f1_score

isol_test_f1 = f1_score(test_label, isol_test_pred == -1)

In [25]:

print(f"Isolation Forest Test F1-Score is {isol_test_f1:.4f}")

Isolation Forest Test F1-Score is 0.6286

2.3 시각화¶

In [26]:

isol_Z = isol_forest.predict(np.c_[xx.ravel(), yy.ravel()])
isol_Z = isol_Z.reshape(xx.shape)

In [27]:

cs = plt.contourf(xx, yy, isol_Z, cmap=plt.cm.Paired)
plt.scatter(train_data[:,0], train_data[:,1], c=train_label)

Out[27]:

<matplotlib.collections.PathCollection at 0x7f16f2f81550>

In [28]:

cs = plt.contourf(xx, yy, isol_Z, cmap=plt.cm.Paired)
plt.scatter(test_data[:,0], test_data[:,1], c=test_label)

Out[28]:

<matplotlib.collections.PathCollection at 0x7f16f2f81690>

3. OCSVM¶

3.1 학습 & 예측¶

In [29]:

from sklearn.svm import OneClassSVM

ocsvm = OneClassSVM()

In [30]:

ocsvm.fit(train_data, train_label)

Out[30]:

OneClassSVM()

In [31]:

ocsvm_test_pred = ocsvm.predict(test_data)

In [32]:

ocsvm_test_pred

Out[32]:

array([ 1, -1, -1, -1, -1,  1,  1,  1,  1,  1,  1, -1,  1, -1,  1, -1,  1,
       -1, -1,  1, -1,  1, -1, -1, -1, -1, -1,  1, -1,  1,  1, -1,  1,  1,
       -1,  1, -1, -1, -1,  1,  1,  1, -1,  1, -1, -1,  1, -1, -1, -1, -1,
       -1, -1,  1, -1, -1,  1, -1, -1, -1])

3.2 평가¶

정확도

In [35]:

ocsvm_test_acc = accuracy_score(test_label, ocsvm_test_pred == -1)

In [36]:

print(f"OCSVM Test Accuracy is {ocsvm_test_acc:.4f}")

OCSVM Test Accuracy is 0.5667

F1 Score

In [37]:

ocsvm_test_f1 = f1_score(test_label, ocsvm_test_pred == -1)

In [38]:

print(f"OCSVM Test F1-Score is {ocsvm_test_f1:.4f}")

OCSVM Test F1-Score is 0.4800

3.3 시각화¶

In [39]:

ocsvm_Z = ocsvm.predict(np.c_[xx.ravel(), yy.ravel()])
ocsvm_Z = ocsvm_Z.reshape(xx.shape)

In [40]:

cs = plt.contourf(xx, yy, ocsvm_Z, cmap=plt.cm.Paired)
plt.scatter(train_data[:,0], train_data[:,1], c=train_label)

Out[40]:

<matplotlib.collections.PathCollection at 0x7f16f2cec190>

In [41]:

cs = plt.contourf(xx, yy, ocsvm_Z, cmap=plt.cm.Paired)
plt.scatter(test_data[:,0], test_data[:,1], c=test_label)

Out[41]:

<matplotlib.collections.PathCollection at 0x7f16f2c0ce90>

4. PCA¶

4.1 학습 & 예측¶

In [42]:

from sklearn.decomposition import PCA

pca = PCA(n_components=1)

In [43]:

pca.fit(train_data)

Out[43]:

PCA(n_components=1)

In [44]:

test_latent = pca.transform(test_data)

In [46]:

test_latent[:10]

Out[46]:

array([[ 2.96603448e-01],
       [ 1.24231267e+00],
       [ 1.06281107e+00],
       [-7.40403889e-01],
       [-1.04768362e+00],
       [ 1.06747491e-01],
       [ 2.14169771e-01],
       [-2.90818242e-01],
       [-6.48459113e-01],
       [-2.02332106e-04]])

In [47]:

test_recon = pca.inverse_transform(test_latent)

In [49]:

recon_diff = (test_data - test_recon) ** 2

In [51]:

test_data[0]

Out[51]:

array([0.37198025, 0.49392302])

In [52]:

test_recon[0]

Out[52]:

array([0.34662995, 0.7059456 ])

In [50]:

recon_diff[0]

Out[50]:

array([0.00064264, 0.04495357])

In [53]:

pca_pred = recon_diff.mean(1)

In [54]:

pca_pred[:10]

Out[54]:

array([2.27981061e-02, 1.27982521e-02, 2.23592395e-01, 2.53514995e-01,
       2.49587527e-01, 1.10212458e-01, 4.89886192e-02, 1.10896685e-02,
       5.78102995e-05, 7.73374114e-03])

4.2 평가¶

In [55]:

from sklearn.metrics import roc_curve, auc


fpr, tpr, threshold = roc_curve(test_label, pca_pred)
pca_auroc = auc(fpr, tpr)

In [56]:

plt.plot(fpr, tpr)

Out[56]:

[<matplotlib.lines.Line2D at 0x7f16ec916b10>]

In [57]:

print(f"PCA test AUROC is {pca_auroc:.4f}")

PCA test AUROC is 0.7052

Best Threshold

In [58]:

f1_scores = []
for t in threshold:
    pca_test_pred = pca_pred > t
    pca_test_f1 = f1_score(test_label, pca_test_pred)
    f1_scores += [pca_test_f1]
    print(f"threshold: {t:.4f}, f1-score: {pca_test_f1:.4f}")

threshold: 2.7621, f1-score: 0.0000
threshold: 1.7621, f1-score: 0.0000
threshold: 1.2702, f1-score: 0.2353
threshold: 0.9820, f1-score: 0.3333
threshold: 0.7935, f1-score: 0.4000
threshold: 0.7125, f1-score: 0.4762
threshold: 0.5471, f1-score: 0.5833
threshold: 0.2236, f1-score: 0.4444
threshold: 0.1373, f1-score: 0.4324
threshold: 0.1082, f1-score: 0.4390
threshold: 0.1044, f1-score: 0.4286
threshold: 0.0748, f1-score: 0.4348
threshold: 0.0567, f1-score: 0.4255
threshold: 0.0267, f1-score: 0.3929
threshold: 0.0229, f1-score: 0.3860
threshold: 0.0187, f1-score: 0.4068
threshold: 0.0163, f1-score: 0.4000
threshold: 0.0145, f1-score: 0.4262
threshold: 0.0140, f1-score: 0.4194
threshold: 0.0077, f1-score: 0.4179
threshold: 0.0076, f1-score: 0.4118
threshold: 0.0001, f1-score: 0.4054

In [60]:

best_thresh = threshold[np.argmax(f1_scores)]
best_thresh

Out[60]:

0.5471488977187242

In [61]:

pca_test_pred = pca_pred > best_thresh

In [62]:

pca_test_pred

Out[62]:

array([False, False, False, False, False, False, False, False, False,
       False, False, False, False, False, False,  True, False, False,
       False, False, False, False, False,  True, False, False, False,
       False, False, False, False, False, False, False, False, False,
       False, False, False, False, False, False, False, False, False,
       False, False,  True, False, False,  True, False,  True, False,
        True,  True, False, False,  True,  True])

정확도

In [63]:

pca_test_acc = accuracy_score(test_label, pca_test_pred)

In [64]:

print(f"PCA Test Accuracy is {pca_test_acc:.4f}")

PCA Test Accuracy is 0.8333

F1 Score

In [65]:

pca_test_f1 = f1_score(test_label, pca_test_pred)

In [66]:

print(f"PCA Test F1-Score is {pca_test_f1:.4f}")

PCA Test F1-Score is 0.5833

4.3 시각화¶

In [67]:

Z = np.c_[xx.ravel(), yy.ravel()]
Z_latent = pca.transform(Z)
Z_recon = pca.inverse_transform(Z_latent)
pca_Z = (Z - Z_recon).mean(1)

In [68]:

pca_Z = list(map(int, pca_Z > best_thresh))

In [69]:

pca_Z = np.array(pca_Z).reshape(xx.shape)

In [70]:

cs = plt.contourf(xx, yy, pca_Z, cmap=plt.cm.Paired)
plt.scatter(train_data[:,0], train_data[:,1], c=train_label)

Out[70]:

<matplotlib.collections.PathCollection at 0x7f16f2b95910>

In [71]:

cs = plt.contourf(xx, yy, pca_Z, cmap=plt.cm.Paired)
plt.scatter(test_data[:,0], test_data[:,1], c=test_label)

Out[71]:

<matplotlib.collections.PathCollection at 0x7f16e4078f90>

5. 마무리¶

5.1 정확도¶

In [72]:

print(f"Isolation Forest Test Accuracy is {isol_test_acc:.4f}")
print(f"OCSVM Test Accuracy is {ocsvm_test_acc:.4f}")
print(f"PCA Test Accuracy is {pca_test_acc:.4f}")

Isolation Forest Test Accuracy is 0.7833
OCSVM Test Accuracy is 0.5667
PCA Test Accuracy is 0.8333

5.2 F1-Score¶

In [73]:

print(f"Isolation Forest Test F1-Score is {isol_test_f1:.4f}")
print(f"OCSVM Test F1-Score is {ocsvm_test_f1:.4f}")
print(f"PCA Test F1-Score is {pca_test_f1:.4f}")

Isolation Forest Test F1-Score is 0.6286
OCSVM Test F1-Score is 0.4800
PCA Test F1-Score is 0.5833

In [ ]:

out-of-distribution detection

샘플 데이터와 Out-of-Distribution 모델¶

1. Data¶

1.1 Sample Data¶

1.2 Resample Data¶

1.3 Split Data¶

1.4 시각화 데이터¶

2. Isolation Forest¶

2.1 학습 & 예측¶

2.2 평가¶

2.3 시각화¶

3. OCSVM¶

3.1 학습 & 예측¶

3.2 평가¶

3.3 시각화¶

4. PCA¶

4.1 학습 & 예측¶

4.2 평가¶

4.3 시각화¶

5. 마무리¶

5.1 정확도¶

5.2 F1-Score¶

'Machine Learning > Abnomaly Detection' 카테고리의 다른 글

티스토리툴바
