샘플 데이터와 Boosting Classification









샘플 데이터와 Boosting Classification¶



In [1]:

import pandas as pd
import numpy as np
import matplotlib.pyplot as plt


np.random.seed(2021)





1. Data¶





1.1 Sample Data¶





실습에서 사용할 데이터를 생성해보겠습니다.



In [2]:

from sklearn.datasets import make_gaussian_quantiles


data_1, label_1 = make_gaussian_quantiles(
    cov=2, n_samples=200, n_features=2, n_classes=2, random_state=2021
)
data_2, label_2 = make_gaussian_quantiles(
    mean=(3, 3), cov=1.5, n_samples=300, n_features=2, n_classes=2, random_state=2021
)



In [3]:

data = np.concatenate((data_1, data_2))
label = np.concatenate((label_1, - label_2 + 1))



In [4]:

plt.scatter(data[:,0], data[:,1], c=label)



Out[4]:

<matplotlib.collections.PathCollection at 0x7f6195cea2d0>







1.2 Data Split¶



In [5]:

from sklearn.model_selection import train_test_split

train_data, test_data, train_label, test_label = train_test_split(
    data, label, train_size=0.7, random_state=2021
)





1.3 시각화 데이터¶



In [6]:

x_min, x_max = data[:, 0].min() - 1, data[:, 0].max() + 1
y_min, y_max = data[:, 1].min() - 1, data[:, 1].max() + 1
xx, yy = np.meshgrid(np.arange(x_min, x_max, 0.02),
                     np.arange(y_min, y_max, 0.02))





2. Decision Tree¶





우선 기본적인 Decision Tree를 학습후 결과를 비교해 보겠습니다.



In [7]:

from sklearn.tree import DecisionTreeClassifier


tree = DecisionTreeClassifier(max_depth=2)





2.1 학습¶



In [8]:

tree.fit(train_data, train_label)



Out[8]:

DecisionTreeClassifier(ccp_alpha=0.0, class_weight=None, criterion='gini',
                       max_depth=2, max_features=None, max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, presort='deprecated',
                       random_state=None, splitter='best')





2.2 예측¶



In [9]:

tree_train_pred = tree.predict(train_data)
tree_test_pred = tree.predict(test_data)





2.3 평가¶



In [10]:

from sklearn.metrics import accuracy_score

tree_train_acc = accuracy_score(train_label, tree_train_pred)
tree_test_acc = accuracy_score(test_label, tree_test_pred)



In [11]:

print(f"Tree train accuray is {tree_train_acc:.4f}")
print(f"Tree test accuray is {tree_test_acc:.4f}")





Tree train accuray is 0.7286
Tree test accuray is 0.6867





2.4 시각화¶



In [12]:

tree_Z = tree.predict(np.c_[xx.ravel(), yy.ravel()])
tree_Z = tree_Z.reshape(xx.shape)



In [13]:

plt.figure(figsize=(14, 7))
plt.subplot(121)
cs = plt.contourf(xx, yy, tree_Z, cmap=plt.cm.Paired)
plt.scatter(train_data[:,0], train_data[:,1], c=train_label)
plt.title("train data")

plt.subplot(122)
cs = plt.contourf(xx, yy, tree_Z, cmap=plt.cm.Paired)
plt.scatter(test_data[:,0], test_data[:,1], c=test_label)
plt.title("test data")



Out[13]:

Text(0.5, 1.0, 'test data')







3. AdaBoost¶





다음은 AdaBoost를 학습해 보겠습니다. AdaBoost는 sklearn.ensemble의 AdaBoostClassifier로 생성할 수 있습니다.
AdaBoostClassifier는 base_estimator를 선언해주어야 합니다.
가장 간단한 if else로 데이터가 분류 될 수 있도록 depth가 1인 tree로 base estimator로 만들겠습니다.



In [14]:

from sklearn.ensemble import AdaBoostClassifier


ada_boost = AdaBoostClassifier(DecisionTreeClassifier(max_depth=1))





3.1 학습¶



In [15]:

ada_boost.fit(train_data, train_label)



Out[15]:

AdaBoostClassifier(algorithm='SAMME.R',
                   base_estimator=DecisionTreeClassifier(ccp_alpha=0.0,
                                                         class_weight=None,
                                                         criterion='gini',
                                                         max_depth=1,
                                                         max_features=None,
                                                         max_leaf_nodes=None,
                                                         min_impurity_decrease=0.0,
                                                         min_impurity_split=None,
                                                         min_samples_leaf=1,
                                                         min_samples_split=2,
                                                         min_weight_fraction_leaf=0.0,
                                                         presort='deprecated',
                                                         random_state=None,
                                                         splitter='best'),
                   learning_rate=1.0, n_estimators=50, random_state=None)





3.2 예측¶



In [16]:

ada_boost_train_pred = ada_boost.predict(train_data)
ada_boost_test_pred = ada_boost.predict(test_data)





3.3 평가¶



In [17]:

from sklearn.metrics import accuracy_score

ada_boost_train_acc = accuracy_score(train_label, ada_boost_train_pred)
ada_boost_test_acc = accuracy_score(test_label, ada_boost_test_pred)



In [18]:

print(f"Ada Boost train accuray is {ada_boost_train_acc:.4f}")
print(f"Ada Boost test accuray is {ada_boost_test_acc:.4f}")





Ada Boost train accuray is 0.9486
Ada Boost test accuray is 0.8600





3.4 시각화¶



In [19]:

ada_boost_Z = ada_boost.predict(np.c_[xx.ravel(), yy.ravel()])
ada_boost_Z = ada_boost_Z.reshape(xx.shape)



In [20]:

plt.figure(figsize=(14, 7))

plt.subplot(121)
cs = plt.contourf(xx, yy, ada_boost_Z, cmap=plt.cm.Paired)
plt.scatter(train_data[:,0], train_data[:,1], c=train_label)
plt.title("train_data")

plt.subplot(122)
cs = plt.contourf(xx, yy, ada_boost_Z, cmap=plt.cm.Paired)
plt.scatter(test_data[:,0], test_data[:,1], c=test_label)
plt.title("test_data")



Out[20]:

Text(0.5, 1.0, 'test_data')







4. GradientBoost¶





다음은 Gradient Boost입니다.
Gradient Boost는 sklearn.ensemble 의 GradientBoostingClassifier로 생성할 수 있습니다.
Gradient Boost또한 간단한 if else로 만들 수 있도록 max_depth를 1로 주겠습니다.



In [21]:

from sklearn.ensemble import GradientBoostingClassifier

grad_boost = GradientBoostingClassifier(max_depth=1)





4.1 학습¶



In [22]:

grad_boost.fit(train_data, train_label)



Out[22]:

GradientBoostingClassifier(ccp_alpha=0.0, criterion='friedman_mse', init=None,
                           learning_rate=0.1, loss='deviance', max_depth=1,
                           max_features=None, max_leaf_nodes=None,
                           min_impurity_decrease=0.0, min_impurity_split=None,
                           min_samples_leaf=1, min_samples_split=2,
                           min_weight_fraction_leaf=0.0, n_estimators=100,
                           n_iter_no_change=None, presort='deprecated',
                           random_state=None, subsample=1.0, tol=0.0001,
                           validation_fraction=0.1, verbose=0,
                           warm_start=False)





4.2 예측¶



In [23]:

grad_boost_train_pred = grad_boost.predict(train_data)
grad_boost_test_pred = grad_boost.predict(test_data)





4.3 평가¶



In [24]:

from sklearn.metrics import accuracy_score

grad_boost_train_acc = accuracy_score(train_label, grad_boost_train_pred)
grad_boost_test_acc = accuracy_score(test_label, grad_boost_test_pred)



In [25]:

print(f"Gradient Boost train accuray is {grad_boost_train_acc:.4f}")
print(f"Gradient Boost test accuray is {grad_boost_test_acc:.4f}")





Gradient Boost train accuray is 0.8886
Gradient Boost test accuray is 0.8200





4.4 시각화¶



In [26]:

grad_boost_Z = grad_boost.predict(np.c_[xx.ravel(), yy.ravel()])
grad_boost_Z = grad_boost_Z.reshape(xx.shape)



In [27]:

plt.figure(figsize=(14, 7))

plt.subplot(121)
cs = plt.contourf(xx, yy, grad_boost_Z, cmap=plt.cm.Paired)
plt.scatter(train_data[:,0], train_data[:,1], c=train_label)
plt.title("train_data")

plt.subplot(122)
cs = plt.contourf(xx, yy, grad_boost_Z, cmap=plt.cm.Paired)
plt.scatter(test_data[:,0], test_data[:,1], c=test_label)
plt.title("test_data")



Out[27]:

Text(0.5, 1.0, 'test_data')







5. 마무리¶



In [28]:

print(f"Tree test accuray is {tree_test_acc:.4f}")
print(f"Gradient Boost test accuray is {grad_boost_test_acc:.4f}")
print(f"Ada Boost test accuray is {ada_boost_test_acc:.4f}")





Tree test accuray is 0.6867
Gradient Boost test accuray is 0.8200
Ada Boost test accuray is 0.8600



In [29]:

fig, axes = plt.subplots(nrows=1, ncols=3, figsize=(15, 5))
Z_name = [
    ("tree", tree_Z),
    ("Ada Boost", ada_boost_Z),
    ("Gradient Boost", grad_boost_Z)
]
for idx, (name, Z) in enumerate(Z_name):
    ax = axes[idx]
    ax.contourf(xx, yy, Z, cmap=plt.cm.Paired)
    ax.scatter(train_data[:,0], train_data[:,1], c=train_label)
    ax.set_title(name)







In [ ]:
