Iris 데이터를 이용한 SVM 커널 실습¶

In [1]:

import pandas as pd
import numpy as np
import matplotlib.pyplot as plt


np.random.seed(2021)

1. Data¶

In [2]:

from sklearn.datasets import load_iris

iris = load_iris()

data = iris.data
target = iris.target

In [3]:

data = data[target !=0, :2]
target = target[target !=0]

In [4]:

plt.scatter(data[:, 0], data[:, 1], c=target)

Out[4]:

<matplotlib.collections.PathCollection at 0x7fc2b3d62ed0>

In [5]:

from sklearn.model_selection import train_test_split

train_data, test_data, train_target, test_target = train_test_split(
    data, target, train_size=0.9, random_state=2021
)

2. Linear Kernel¶

SVM은 sklearn.svm 의 SVC로 사용할 수 있습니다.

In [6]:

from sklearn.svm import SVC

우선 가장 기본적인 svm 커널인 linear 커널을 사용해 보겠습니다

In [7]:

linear_svc = SVC(kernel="linear")

In [8]:

linear_svc.fit(train_data, train_target)

Out[8]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma='scale', kernel='linear',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

아래는 svm의 결과를 시각화 하기 위한 함수입니다.

In [9]:

def plot_support_vector_machine(svm):
    # 전체 데이터
    plt.scatter(data[:, 0], data[:, 1], c=target, zorder=10, cmap=plt.cm.Paired,
                edgecolor='k', s=20)
    # test 데이터
    plt.scatter(test_data[:, 0], test_data[:, 1], s=80, facecolors='none',
                zorder=10, edgecolor='k')

    plt.axis('tight')
    x_min = data[:, 0].min()
    x_max = data[:, 0].max()
    y_min = data[:, 1].min()
    y_max = data[:, 1].max()

    # 영역 칠하기
    XX, YY = np.mgrid[x_min:x_max:200j, y_min:y_max:200j]
    Z = svm.decision_function(np.c_[XX.ravel(), YY.ravel()])

    Z = Z.reshape(XX.shape)
    plt.pcolormesh(XX, YY, Z > 0, cmap=plt.cm.Paired, shading="auto")
    plt.contour(XX, YY, Z, colors=['k', 'k', 'k'],
                linestyles=['--', '-', '--'], levels=[-.5, 0, .5])

아래 plot의 속성들은 다음과 같습니다.

decision boundary
- 검은색 직선
support vector
- 검은색 점선
영역
- 클래스로 구별되는 영역

In [10]:

plt.figure(figsize=(7,7))
plot_support_vector_machine(linear_svc)

3. Poly Kernel¶

다음으로 알아볼 커널은 poly 커널 입니다.
poly커널은 직선을 곡선으로 mapping 시켜주는 커널입니다.
poly커널에 영향을 미치는 argument들은 다음과 같습니다.

gamma
- 결경 경계를 스케일링해주는 값입니다.
degree
- 몇 차원의 곡선으로 맵핑할지 정해주는 값입니다.

3.1 gamma¶

3.1.1 "scale"¶

default 옵션은 자동으로 scaling 해줍니다.

In [11]:

poly_svc = SVC(kernel="poly")

In [12]:

poly_svc.fit(train_data, train_target)

Out[12]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma='scale', kernel='poly',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [13]:

plt.figure(figsize=(7,7))
plot_support_vector_machine(poly_svc)

3.1.2 gamma=0.1¶

gamma값을 작게 주면 다음과 같습니다.

In [14]:

poly_svc = SVC(kernel="poly", gamma=0.1)
poly_svc.fit(train_data, train_target)

Out[14]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma=0.1, kernel='poly',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [15]:

plt.figure(figsize=(7,7))
plot_support_vector_machine(poly_svc)

3.1.3 gamma=10¶

gamma값을 크게 주면 다음과 같습니다.

In [16]:

poly_svc = SVC(kernel="poly", gamma=10)
poly_svc.fit(train_data, train_target)

Out[16]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma=10, kernel='poly',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [17]:

plt.figure(figsize=(7,7))
plot_support_vector_machine(poly_svc)

3.2 degree¶

3.2.1 degree=2¶

In [18]:

poly_svc = SVC(kernel="poly", gamma=10, degree=2)
poly_svc.fit(train_data, train_target)

Out[18]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=2, gamma=10, kernel='poly',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [19]:

plt.figure(figsize=(7,7))
plot_support_vector_machine(poly_svc)

3.2.1 degree=4¶

In [20]:

poly_svc = SVC(kernel="poly", gamma=10, degree=4)
poly_svc.fit(train_data, train_target)

Out[20]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=4, gamma=10, kernel='poly',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [21]:

plt.figure(figsize=(7,7))
plot_support_vector_machine(poly_svc)

4. RBF Kernel¶

다음으로 알아볼 것은 rbf커널 입니다.
rbf 커널은 데이터를 고차원의 공간으로 mapping시켜줍니다.
rbf또한 gamma 값으로 scaling을 합니다.

4.1 "scale"¶

In [22]:

rbf_svc = SVC(kernel="rbf")
rbf_svc.fit(train_data, train_target)

Out[22]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma='scale', kernel='rbf',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [23]:

plt.figure(figsize=(7, 7))
plot_support_vector_machine(rbf_svc)

4.2 gamma=0.1¶

In [24]:

rbf_svc = SVC(kernel="rbf", gamma=0.1)
rbf_svc.fit(train_data, train_target)

Out[24]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma=0.1, kernel='rbf',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [25]:

plt.figure(figsize=(7, 7))
plot_support_vector_machine(rbf_svc)

4.3 gamma=10¶

In [26]:

rbf_svc = SVC(kernel="rbf", gamma=10)
rbf_svc.fit(train_data, train_target)

Out[26]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma=10, kernel='rbf',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [27]:

plt.figure(figsize=(7, 7))
plot_support_vector_machine(rbf_svc)

5. Penalty¶

패너티는 C argument를 통해 줄 수 있습니다.

5.1 Poly¶

In [28]:

poly_svc = SVC(kernel="poly", gamma=10)
poly_svc.fit(train_data, train_target)

Out[28]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma=10, kernel='poly',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [29]:

hard_penalty_poly_svc = SVC(kernel="poly", gamma=10, C=100)
hard_penalty_poly_svc.fit(train_data, train_target)

Out[29]:

SVC(C=100, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma=10, kernel='poly',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [30]:

plt.figure(figsize=(14, 7))
plt.subplot(1,2,1)
plot_support_vector_machine(poly_svc)
plt.title("No penalty")
plt.subplot(1,2,2)
plot_support_vector_machine(hard_penalty_poly_svc)
plt.title("Hard penalty")

Out[30]:

Text(0.5, 1.0, 'Hard penalty')

5.2 RBF¶

In [31]:

rbf_svc = SVC(kernel="rbf", gamma=10)
rbf_svc.fit(train_data, train_target)

Out[31]:

SVC(C=1.0, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma=10, kernel='rbf',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [32]:

hard_penalty_svc = SVC(kernel="rbf", gamma=10, C=100)
hard_penalty_svc.fit(train_data, train_target)

Out[32]:

SVC(C=100, break_ties=False, cache_size=200, class_weight=None, coef0=0.0,
    decision_function_shape='ovr', degree=3, gamma=10, kernel='rbf',
    max_iter=-1, probability=False, random_state=None, shrinking=True,
    tol=0.001, verbose=False)

In [33]:

plt.figure(figsize=(14, 7))
plt.subplot(1,2,1)
plot_support_vector_machine(rbf_svc)
plt.title("No penalty")
plt.subplot(1,2,2)
plot_support_vector_machine(hard_penalty_svc)
plt.title("Hard penalty")

Out[33]:

Text(0.5, 1.0, 'Hard penalty')

In [ ]:
